Magtek eDynamo BlueTooth

Securely accept magstripe and chip cards using your iPhone, iPad, Android or Windows devices.

Go wireless or connect via USB

Go Bluetooth LE and connect to your favorite iOS, Android or Windows device. The low energy power consumption extends the life of its rechargeable batteries. If wireless is not preferred, then use the Micro-USB cable and connect to a PC or mobile device with a USB host.

Handheld or docked, you choose

Take eDynamo mobile and hold it in your hand. The optional docking station gives merchants the ability to extend the length of the swipe path and mount the device where it makes sense for comfortable card reading.

EMV compliance made simple

A suite of Software Development Kits are available for Apple, Android and Windows operating systems.

Manufacturer: Magtek
Delivery date: 1-2 days
$187.50
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Standard Configurations

DescriptionP/N
Black, EMV Chip and swipe reader21079802
Optional docking station21079809

General Information

InterfacesWireless
USB HID
ColorBlack
Magstripe3 track, ISO 7810 and ISO 7811/ AAMVA
EMV ChipEMV LEVEL1 CONTACT and EMV LEVEL2 CONTACT
Operating SystemiOS 7.1 and newer and Android 4.4.2 and newer
USBWindows 7/8/10
WirelessWindows 8.1 on hosts with Wireless hardware
Card Speed4/6 to 60 ips (10.1 to 152.4 cm/s)
EMV insertions100k

Security and Certifications

Compliance
MagneSafe SecurityTriple DES encryption, DUKPT key management, Tokenization, Authentication, Dynamic Data
MagnePrIntCard authentication, counterfeit card detection
Tamper ResistanceTamper resistant and evident
Remote ServicesVia USB connection
Device ManagementUnique non-changeable serial number, time-bound session IDs

Electrical


Power Input5V from USB bus
Current
Normal mode110 mA maximum

Mechanical


DimensionsLength: 2.48 in (62.9mm)
Width: 0.96 in (38.5mm)
Height: 1.52 in (24.5mm)
Cable Length6 ft.
Wired ConnectionMicro-USB B, configured to appear as HID
Wireless Connection TypesWireless configured to appear as a GATT device
Wireless RangeMinimum 33 ft. (10 m) in line-of-sight conditions

Environmental


Temperature
Operating0 °C to 45 °C (-32 °F to 113 °F)
Storage-20 °C to 60 °C (-4 °F to 140 °F)
Humidity
Operating5% to 90% noncondensing
Storage5% to 90% noncondensing
Altitude
Operating0-10,000 ft. (0-3048 m.)
Storage0-10,000 ft. (0-3048 m.)
